Divesoft Solo Trimix Analyser

Divesoft SOLO Trimix Analyser - Speed of Sound Precision

The lightweight and robust body of Divesoft SOLO Trimix Analyser is made from ABS-PC. It offers an easy-to-read display and intuitive controls.

The USB-C connector makes programming easy and allows the device to charge fully in under four hours. The three-point calibration system ensures precise measurements, allowing you to explore the depths confidently.

The SOLO also has an in-built calculator for mixing gases.

The Divesoft SOLO Trimix Analyser can identify other gases and mixtures used for diving. In case of a hypoxic mixture without another inert gas other than nitrogen, it will warn and recommend you not to breathe such mixture through the “FOUL AIR” warning. It can also identify argon and measure its purity in a special setting.

Divesoft SOLO uses the speed of sound

This He/O2 Analyser uses Divesoft's patented method of measuring helium content based on the speed of sound. This makes the Divesoft Analyser an accurate benchmark. You can own the analyser without the additional cost of purchasing Helium sensors, offering top-of-the-line precision.

• Intelligent firmware

Firmware is designed to provide real-time gas calculations for the most accurate cylinder labelling.

• Easy cell replacement

Uses Teledyne or Analytical Industries Oxygen cell with easy access replacement.

• Lightweight and robust Trimix Analyser


Made from lightweight materials to be a perfect blend of affordability, minimum weight, and optimum robustness for field conditions.

• Streamlined design

Designed to fit comfortably in hand for ease of gas analysis.

• Li-Ion battery

Rechargeable Li-Ion battery and USB-C connector. For your convenience as well as for the purpose of continuous gas analysis.

• Semi-hard case

Divesoft SOLO Trimix Analyser comes with our new semi-hard case to protect your SOLO analyser from harsh field environments.

Divesoft SOLO Trimix Analyser includes:

• Analyzer SOLO Analyser
• USB-C cable
• Simple flow limiter
• Semi-hard zipper case

*Oxygen electrochemical sensors and battery built-in analyser carry a limited warranty of 12 months.

• Dimensions: 85 × 205 × 40 mm (31/4 × 77/8 × 11/2 inches)
• Weight: 420 g (without packaging and accessories)
• Oxygen concentration measurement range: 0 to 100%
• Helium concentration measurement range: 0 to 100%
• Measurement temperature: 0 to + 40 ° C (32 - 104 ° F)
• Mixture Pressure: Corresponds to ambient pressure in the range of 700-1100 millibars (20-32 inches Hg), which corresponds to a standard atmosphere at 0 to 3000 m (0-10000 ft)
• Nominal gas flow rate: 0.2 l / min
• Sound speed measurement base: 800 mm
• Measuring cycle: 200ms
• The connection dimensions of the sampler: Standard for a DIN valve (EN 144-2) for 200/300 bars (G 5/8 thread). Samplers with a connection to any standardized or common valves are available on request or as optional equipment
• Oxygen sensor: R22 S (Molex connector)
• Easy to replace O2 sensor
• Oxygen sensor life expectancy: 2 years
• Replaceable battery: Through authorised service centre
• Battery: 120 measurements or 4 hours of continuous operation
• Warranty: 24 months, 12 months on battery
• Charging and programming: USB-C
• Charging time: 3-4 h
• Display: OLED
• Body: ABS-PC
